Async RPC between services with Resonate

Functions in different processes call each other through Resonate. Each call is durable; chains survive crashes anywhere along the path.

A gateway calls service A, which calls service B, which calls service C. Each step uses Resonate's remote function invocation APIs, so the entire chain is durable — a crash on any service resumes the call without re-running prior steps.

The problem#

Cross-service calls inside a request flow are where most distributed systems fall over. The HTTP request from a client is ephemeral — if the client or any service in the chain crashes, the request is lost and has to start over. Teams paper this over with retries, idempotency keys, and saga frameworks; it's a lot of glue, and the seams leak.

Resonate's solution#

Resonate exposes two layers of remote function invocation:

• resonate.rpc(...) — ephemeral to durable. Called from a regular process (like an HTTP handler). The receiving function is durable; the caller is not.
• ctx.rfc(...) / ctx.rfi(...) — durable to durable. Called from inside another durable function. Both ends checkpoint, so the chain stays resumable end-to-end.

rfc (Remote Function Call) blocks the caller until the result returns. rfi (Remote Function Invocation) returns a handle immediately so the caller can do other work and await later.

Code walkthrough#

The example chains a gateway through service-a → service-b. Each service is a separate process that registers its function with the Resonate Server and listens for invocations.

The gateway (ephemeral → durable)#

app.post("/await-chain", async (_req, res) => {
  const promiseId = "await-chain";
  // Ephemeral-to-durable: HTTP handler calls into a durable service.
  const handle = await resonate.beginRpc<number>(
    promiseId,
    "foo",
    "foo",
    resonate.options({ target: "poll://any@service-a" }),
  );
  // Block the HTTP response on the chain's result.
  const message = await handle.result();
  res.status(200).json({ message });
});

@app.route("/await-chain", methods=["POST"])
def await_chain_route_handler():
    promise_id = "await-chain"
    # Ephemeral-to-durable: HTTP handler calls into a durable service.
    handle = resonate.options(target="poll://service-a").rpc(promise_id, "foo")
    # Block the HTTP response on the chain's result.
    message = handle.result()
    return jsonify({"message": message}), 200

resonate.beginRpc (TypeScript) / resonate.rpc (Python) dispatches foo on whichever process is registered as service-a. The promise ID makes the call idempotent — re-running the same handler with the same ID reconnects to the in-flight execution rather than starting a duplicate chain.

Service A → Service B (durable → durable)#

function* foo(ctx: Context): Generator<any, number, any> {
  // ctx.rpc dispatches to service-b and waits for the result.
  // Both sides are durable; the call resumes if either process crashes.
  const result: number = yield* ctx.rpc<number>(
    "bar",
    ctx.options({ target: "poll://any@service-b" }),
  );
  return result + 1;
}

resonate.register("foo", foo);

function* bar(ctx: Context): Generator<any, number, any> {
  const result: number = yield* ctx.rpc<number>(
    "baz",
    ctx.options({ target: "poll://any@service-c" }),
  );
  return result + 1;
}

resonate.register("bar", bar);

// Detached: dispatch and don't wait. Returns immediately.
yield* ctx.detached("qux", ctx.options({ target: "poll://any@service-d" }));

@resonate.register
def foo(ctx):
    # ctx.rfc dispatches to service-b and waits for the result.
    # Both sides are durable; the call resumes if either process crashes.
    result = yield ctx.rfc("bar").options(target="poll://service-b")
    return result + 1

@resonate.register
def bar(ctx):
    result = yield ctx.rfc("baz").options(target="poll://service-c")
    return result + 1

# Detached: dispatch and don't wait.
ctx.rfi("qux").options(target="poll://service-d")

The ctx.rpc / ctx.rfc call inside a durable function is the durable equivalent of await someService.bar(). The result is checkpointed, so a worker that completes bar and then dies still passes its result back when the chain resumes.

Run it locally#

Both repos ship with nine services so you can exercise the await-chain, detached-chain, and fan-out flows.

git clone https://github.com/resonatehq-examples/example-async-rpc-ts
cd example-async-rpc-ts
bun install

brew install resonatehq/tap/resonate
resonate dev

bun run a
bun run b
# ...c through i, one terminal each

bun run gateway

git clone https://github.com/resonatehq-examples/example-async-rpc-py
cd example-async-rpc-py
uv sync

brew install resonatehq/tap/resonate
resonate serve

uv run python src/service_a.py
uv run python src/service_b.py
# ...service_c through service_i, one terminal each

uv run python src/gateway.py

Trigger the await-chain:

curl -X POST http://localhost:5000/await-chain

The gateway logs each step as the chain hops from service-a to service-b to service-c, returning a final value back through the gateway to the HTTP response.

Try the recovery story#

Trigger the chain, then kill service-b while service-c is still working. Restart service-b. The chain resumes — service-b doesn't re-call service-c (its result is already checkpointed); it just returns the cached result up the stack to service-a.
