Deployment patterns

Resonate works in any environment where you can run a server and workers. This guide covers common deployment patterns for different infrastructure choices.

Development and staging

Docker Compose

Use Docker Compose for local development and staging environments. This gives you a complete Resonate stack (server + database + workers) with one command:

docker-compose.yml
YAML
version: "3.8"

services:
  postgres:
    image: postgres:15
    environment:
      POSTGRES_DB: resonate
      POSTGRES_USER: resonate
      POSTGRES_PASSWORD: secret
    volumes:
      - postgres-data:/var/lib/postgresql/data
    healthcheck:
      test: ["CMD-SHELL", "pg_isready -U resonate"]
      interval: 10s
      timeout: 5s
      retries: 5

  resonate-server:
    image: resonatehq/resonate:latest
    ports:
      - "8001:8001"
      - "9090:9090"
    environment:
      RESONATE_STORE_POSTGRES_ENABLE: "true"
      RESONATE_STORE_POSTGRES_HOST: postgres
      RESONATE_STORE_POSTGRES_DATABASE: resonate
      RESONATE_STORE_POSTGRES_USERNAME: resonate
      RESONATE_STORE_POSTGRES_PASSWORD: secret
    depends_on:
      postgres:
        condition: service_healthy

  worker:
    image: your-app:latest
    environment:
      RESONATE_URL: http://resonate-server:8001
    deploy:
      replicas: 3

volumes:
  postgres-data:

Start the stack:

Shell
docker-compose up -d

Scale workers:

Shell
docker-compose up -d --scale worker=10

This pattern works for:

Local development
CI/CD testing
Staging environments
Small production deployments

Kubernetes

Server deployment

The Resonate server runs as a single replica (multi-server coordination is not yet implemented). Use a Deployment with health checks:

server-deployment.yaml
YAML
apiVersion: apps/v1
kind: Deployment
metadata:
  name: resonate-server
spec:
  replicas: 1 # Single server coordinates all workers
  selector:
    matchLabels:
      app: resonate-server
  template:
    metadata:
      labels:
        app: resonate-server
    spec:
      containers:
        - name: server
          image: resonatehq/resonate:latest
          ports:
            - containerPort: 8001
              name: http
            - containerPort: 50051
              name: grpc
            - containerPort: 9090
              name: metrics
          env:
            - name: RESONATE_STORE_POSTGRES_ENABLE
              value: "true"
            - name: RESONATE_STORE_POSTGRES_HOST
              value: "postgres-service"
            - name: RESONATE_STORE_POSTGRES_DATABASE
              valueFrom:
                secretKeyRef:
                  name: postgres-credentials
                  key: database
            - name: RESONATE_STORE_POSTGRES_USERNAME
              valueFrom:
                secretKeyRef:
                  name: postgres-credentials
                  key: username
            - name: RESONATE_STORE_POSTGRES_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: postgres-credentials
                  key: password
          livenessProbe:
            httpGet:
              path: /healthz
              port: 8001
            initialDelaySeconds: 30
            periodSeconds: 10
          readinessProbe:
            httpGet:
              path: /healthz
              port: 8001
            initialDelaySeconds: 5
            periodSeconds: 5
---
apiVersion: v1
kind: Service
metadata:
  name: resonate-server
spec:
  selector:
    app: resonate-server
  ports:
    - name: http
      port: 8001
      targetPort: 8001
    - name: grpc
      port: 50051
      targetPort: 50051
    - name: metrics
      port: 9090
      targetPort: 9090

Worker deployment

Workers scale horizontally. Use a Deployment with HorizontalPodAutoscaler:

worker-deployment.yaml
YAML
apiVersion: apps/v1
kind: Deployment
metadata:
  name: resonate-workers
spec:
  replicas: 10 # Initial worker count
  selector:
    matchLabels:
      app: resonate-worker
  template:
    metadata:
      labels:
        app: resonate-worker
    spec:
      containers:
        - name: worker
          image: your-app:latest
          env:
            - name: RESONATE_URL
              value: "http://resonate-server:8001"
            - name: WORKER_GROUP
              value: "workers"
          resources:
            requests:
              cpu: "500m"
              memory: "512Mi"
            limits:
              cpu: "1000m"
              memory: "1Gi"
---
apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: resonate-workers-hpa
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: resonate-workers
  minReplicas: 5
  maxReplicas: 50
  metrics:
    - type: Resource
      resource:
        name: cpu
        target:
          type: Utilization
          averageUtilization: 70

The HPA automatically scales worker pods based on CPU utilization.

Serverless platforms

Google Cloud Run

Cloud Run workers can scale to zero and handle variable load automatically:

Dockerfile
Dockerfile
FROM node:20-slim
WORKDIR /app
COPY package*.json ./
RUN npm ci --production
COPY . .
CMD ["node", "worker.js"]

Build and deploy
Shell
# Build container
docker build -t gcr.io/your-project/resonate-worker:latest .

# Push to GCR
docker push gcr.io/your-project/resonate-worker:latest

# Deploy to Cloud Run
gcloud run deploy resonate-worker \
  --image gcr.io/your-project/resonate-worker:latest \
  --set-env-vars RESONATE_URL=https://resonate.example.com \
  --min-instances 1 \
  --max-instances 100 \
  --cpu 1 \
  --memory 512Mi \
  --region us-central1

Cloud Run workers stay alive polling for tasks and scale automatically based on load.

AWS Lambda

Lambda workers can run as functions that poll for tasks or respond to events:

lambda-worker.ts
TypeScript
import { Resonate } from "@resonatehq/sdk";

const resonate = Resonate.remote({
  url: process.env.RESONATE_URL!,
  group: "lambda-workers",
});

// Lambda handler polls for tasks
export async function handler(event: any) {
  // Poll and process tasks
  // Return when done or Lambda timeout approaches
}

Deployment (using AWS CDK):

worker-stack.ts
TypeScript
import * as cdk from "aws-cdk-lib";
import * as lambda from "aws-cdk-lib/aws-lambda";

export class ResonateWorkerStack extends cdk.Stack {
  constructor(scope: cdk.App, id: string) {
    super(scope, id);

    new lambda.Function(this, "ResonateWorker", {
      runtime: lambda.Runtime.NODEJS_20_X,
      handler: "lambda-worker.handler",
      code: lambda.Code.fromAsset("dist"),
      environment: {
        RESONATE_URL: "https://resonate.example.com",
      },
      timeout: cdk.Duration.minutes(15),
      memorySize: 512,
    });
  }
}

Serverless execution limits

Lambda has a 15-minute execution limit. Cloud Run supports longer executions (up to 60 minutes). Design your functions to complete within these limits, or use containerized workers for long-running workflows.

AWS Fargate

Fargate runs containers without managing servers, similar to Cloud Run:

task-definition.json
JSON
{
  "family": "resonate-worker",
  "networkMode": "awsvpc",
  "requiresCompatibilities": ["FARGATE"],
  "cpu": "512",
  "memory": "1024",
  "containerDefinitions": [
    {
      "name": "worker",
      "image": "your-account.dkr.ecr.us-east-1.amazonaws.com/resonate-worker:latest",
      "environment": [
        {
          "name": "RESONATE_URL",
          "value": "https://resonate.example.com"
        }
      ],
      "logConfiguration": {
        "logDriver": "awslogs",
        "options": {
          "awslogs-group": "/ecs/resonate-worker",
          "awslogs-region": "us-east-1",
          "awslogs-stream-prefix": "ecs"
        }
      }
    }
  ]
}

Create a Fargate service that runs the task definition, and Fargate handles scheduling and scaling.

Bare metal / VMs

Systemd service

Run Resonate server as a systemd service on bare metal or VMs:

/etc/systemd/system/resonate.service
INI
[Unit]
Description=Resonate Server
After=network.target postgresql.service

[Service]
Type=simple
User=resonate
WorkingDirectory=/opt/resonate
ExecStart=/usr/local/bin/resonate serve --config /etc/resonate/config.yaml
Restart=on-failure
RestartSec=10

[Install]
WantedBy=multi-user.target

Enable and start:

Shell
sudo systemctl enable resonate
sudo systemctl start resonate

Worker processes

Run workers as separate systemd services or use a process manager like PM2:

PM2 worker management
Shell
# Start 10 workers
pm2 start worker.js -i 10 --name "resonate-worker"

# Scale to 20 workers
pm2 scale resonate-worker 20

# Monitor
pm2 monit

Hybrid deployments

You can mix deployment patterns:

Example: Server on Kubernetes, workers on Cloud Run

Central server in GKE for stability
Workers on Cloud Run for auto-scaling and cost efficiency

Example: Server on VM, workers in Lambda

Self-hosted server for control
Serverless workers for variable load

Resonate doesn't care where workers run as long as they can reach the server.

Which pattern to choose?

Start simple, scale as needed:

Use case	Recommended pattern
Local development	Docker Compose
Small production (<10 workers)	Docker Compose or single VM
Medium production (10-100 workers)	Kubernetes or Cloud Run
Large production (>100 workers)	Kubernetes with HPA
Variable/unpredictable load	Cloud Run or Fargate
Event-driven workloads	Lambda workers
Cost-sensitive	Cloud Run (scales to zero)

General guidance:

Use managed services for PostgreSQL (RDS, Cloud SQL, etc.)
Start with containers (easier debugging than serverless)
Add auto-scaling when you understand your load patterns
Use serverless for unpredictable or bursty workloads

Summary

Resonate works in any environment:

Containers: Docker Compose, Kubernetes, Fargate, Cloud Run
Serverless: Lambda, Cloud Functions
Bare metal: Systemd, PM2, manual processes

The pattern is always the same:

Run one Resonate server (coordinates work)
Run N workers (execute your code)
Connect workers to server via RESONATE_URL

Choose your infrastructure based on your operational preferences and scale requirements. Resonate adapts to where you want to run.
